Section rough carpentry plywood floor sheathing

1.01 SECTION INCLUDES

A. This section includes labor, materials and other services necessary to complete vinyl wall coverings.

A. Section 03300 - Cast-in-Place Concrete: Concrete finishing.
B. Section 06100 - Rough Carpentry: Plywood floor sheathing.
C. Division 7 - Thermal and Moisture Protection.

D. Division 15 - Mechanical.

Standards subsequently referenced herein are referred to by issuing authority abbreviation and standard designation.

B. American Society for Testing & Materials (ASTM):
1. AST ASTM E 84-05 Standard Test Method for Surface Burning Characteristics of Building Materials. CLASS A

Altro USA, Inc. 2. ASTM D5420 Gardner Impact Exceeds 160 inch pounds

1.04 SYSTEM DESCRIPTION

A. Performance Requirements: Provide hygienic Altro Whiterock Matte wall covering which has been manufactured by Altro and installed to maintain performance criteria stated by manufacturer without defects, damage or failure.

B. Shop Drawings: Submit shop drawings to indicate materials, details, and accessories in accordance with Section 01330 - Submittal Procedures including but limited to the following:
1. Submit a layout diagram indicating the location of each panel and joining method.

C. Samples: Submit duplicate sample pieces of Altro Whiterock Matte material, as well as accessory pieces in accordance with Section 01330 - Submittal Procedures.

3. Manufacturer’s Field Reports: Specified herein.

E. Closeout Submittals: Submit the following:
1. Operation and Maintenance Data: Operation and maintenance data for installed products in accordance with Division 1 Closeout Submittals (Maintenance Data and Operation Data) Section. Include methods for maintaining installed products and precautions against cleaning materials and methods detrimental to finishes and performance.

A. Installer Qualifications: Installer experienced in performing work of this section who has specialized in installation of work similar to that required for this project.

******************************************************************************************************

B. Mock-ups: Install at project site a job mock-up using acceptable products and manufacturer approved installation methods. Obtain Owner’s and Consultant’s acceptance of finish color, texture and pattern, and workmanship standards.

3. Incorporation: Mock-up may be incorporated into final construction upon Owner’s approval.

******************************************************************************************************
Specifier Note: Describe requirements for meetings to coordinate materials and techniques, and to sequence related work.

1.07 DELIVERY, STORAGE & HANDLING

A. Ordering: Comply with manufacturer’s ordering instructions and lead time requirements to avoid construction delays.

1.08 WASTE MANAGEMENT AND DISPOSAL

******************************************************************************************************
Specifier Note: Include information that will assist the contractor in dealing with the disposal of construction waste

******************************************************************************************************

A. Deposit all packaging materials in appropriate container on site for recycling or reuse.

B. Maintain air temperature and structural base temperature at installation area between 65F (18C) and 80F (26C) for 48 hours before, during and 24 hours after installation.

******************************************************************************************************
Specifier Note: Coordinate Article below with Conditions of the Contract and with Division 1 Closeout Submittals (Warranty) Section.

******************************************************************************************************
Specifier Note: Coordinate paragraph below with manufacturer’s warranty requirements. All Altro walling products are sold with a limited product warranty. The length of warranty is defined by the manufacturing process, the thickness of the product and the expected conditions for the specific product. Under normal use and service, Altro walling products are warranted to be free from defects in materials and workmanship within the specified term after the installation date, when installed and maintained in accordance with Altro’s recommendations. Altro Whiterock Matte has a 20-Year warranty.

*****************************************************************************************************

C. Provide [______] sq.ft ([_______] m2) of extra materials in one piece and from same production run as installed materials.

Altro USA, Inc. 800.377.5597 support@altrofloors.com explore altro.com

PART 2 PRODUCTS

******************************************************************************************************

A. Manufacturer: Altro

1. USA: 80 Industrial Way, Wilmington, MA 01887

Specifier Note: Select material to suit project requirements.

A.

Altro WhiterockTM Matte is 100% pure vinyl, extruded, semi-rigid PVCu sheet. Altro Whiterock Matte

(3m); Weight: 28 lbs (12.8 kg).

2. Battleship FT208: Thickness: 0.10" (2.5 mm); Panel Width: 4’ (1.22m) Panel Height: 9’

(3m); Weight: 28 lbs (12.8 kg).

2.03 ACCESSORIES

2. 1-Part Joint Strip – [G831/30 White] Length 118”

3. 2-Part Joint Strip – [A831/25 White] [A831/25/** color] Length 98.5”

support@altrofloors.com explore altro.com

2. 1-Part Start and Edge Trim – [G833/30 White] Length 118”

3. 2-Part Start and Edge Trim – [A833/25 White] [A833/25/** color] Length 98.5”

3. Stainless Steel Capping – [A865 Brushed Steel] Length 8’

4. 18 Gauge Stainless Steel 304 Sheet – [W123/20 Brushed Steel] 6’6” X3’3”

controlled areas, and non-absorbent surfaces, use AltroFix W39, a two-part resin-based

polyurethane adhesive as recommended by manufacturer.

PART 3 EXECUTION

3.01 MANUFACTURER’S INSTRUCTIONS

under other sections, are acceptable for product installation in accordance with manufacturer’s

instructions.

not have to skim grout joints.

C. Surfaces must be permanently dry and free from all substances that may contribute to

CSI Specifications
Altro Whiterock™
Matte

D. Remove loose paint and conduct an adhesive bond test with paint.

A. All surfaces must be free from dust and cleaned prior to Altro Whiterock Matte installation. The working environment must also be dust free. Failure to comply with these conditions will reduce the bond strength between the adhesive and substrate, and may cause the Altro Whiterock Matte panels to debond.

B. Very absorbent / porous substrates (particularly plaster finishes and unprimed sheetrock) must have a proprietary sealer e.g. PVA primer or similar, applied to the surface a minimum of 12 hours prior to the installation.

G. If fitting to door frames, these must be in place prior to installation of Altro Whiterock Matte.

H. Prior to installation, it is advisable to complete any painting which comes in contact with Altro Whiterock Matte, as sealant used at junctions is non-paintable.

******************************************************************************************************

Altro USA, Inc. 800.377.5597 support@altrofloors.com explore altro.com

******************************************************************************************************
Specifier Note: Coordinate Article below with Division 1 Quality Assurance and Quality Control Sections.

******************************************************************************************************

1. Site Visits: [Specify number and duration of periodic site visits.].

3.07 CLEANING

C. Pressure cleaning with hot water may be used with the pressure nozzle a minimum of 2 feet (600mm) away from the surface.

D. To reduce the buildup of static, cleaning the panels with an anti-static solution is recommended.

Altro USA, Inc. 800.377.5597 support@altrofloors.com explore altro.com

used in such areas.

END OF SECTION
