Student must have satisfied all the merit criteria and

The PID controller is widely employed because it is simple, efficient and effective. The PID gains can be designed based upon the system parameters if they can be achieved or estimated precisely. Mat Lab is often used for modelling and simulation of control systems. Task 1.0 The aim of this assignment is to investigate a PID controller for a DC motor modelled in

Fig 2.0Fig 3.0 •the use of Bode-plot to analyse the stability of the DC motor system in Fig 1.0 and justification of the result using Routh-Hurwitz stability criterion. •investigation of the step input response of a PID controllers in terms of position control, tracking and disturbance rejection for dc motor system in Fig 1.0.

HNC/HND Engineering 5


	M1 Apply advanced modelling techniques using commercially available control software M2 Develop the block diagram of a closed loop system for the position control of DC motor using a PID controller
LO2 Explore the elements of a typical, high-level control system and its model development

5 Analyse the behaviour and response of first and second order systems P6 Analyse the external effects on the stability of PID control systems and the techniques used to maintain stability in these systems

P7 Examine the role and implementation of the PID controllers in a simple electrical and mechanical control system P8 Examine the effects of the P, I, and D parameters on the dynamic responses of the first and second order systems	M5 Analyse dynamic responses of PID controllers in terms of position control, tracking and disturbance rejection

showing coverage of the unit content and, therefore, attainment at Level 5.

●To achieve a Merit, a student must have satisfied all the Merit criteria (and, therefore, the Pass
